Bo mạch chủ H510 T-Wolf (DDR4, M-ATX, LGA1200)

Bo mạch chủ H510 T-Wolf (DDR4, M-ATX, LGA1200)

Thương hiệu: T-Wolf

Mã sản phẩm: H510 T-Wolf

1,390,000₫

Chipset Intel H510 Express, LGA 1200 S/p CPU Gen 10-11th
RAM 2xDDR4 Dual channel 2400/2666/3200 MHz s/p Up to 32GB
VGA-DVI-HDMI, Lan 1000M, Audio 5.1, 4*USB2.0, 2*USB3.0
M2 NVMe, 1x PCI Express 16X, 1xPCI Express 1X, 3xSata3.0, Form Factor ATX (17cmx21cm)

====================

Bảo hành 36 tháng

Đặc điểm nổi bật

Thông số kĩ thuật

Thương hiệu	T-WOLF
Mã sản phẩm	TW-H510
SKU	686868510
CPU	Supports 10th/11th (SKYlake). CPU (LG1200)
Chipset	Intel H510 Express Chipset
Memory	2*288-pin DDR4 SDRAM slots
	Memory up to 32GB
	Supports DDR4 3200/2666/2400 memory
I/O interface	1xP/S2 keyboard port,1xPS/2 mouse port
	4xUSB2.0, 2XUSB3.0
	1xDVI port
	1xVGA port
	1xHDMI port
	1xRJ45 port
	1×3-in-1 Audio port(line in/line out/MIC in)
Onboard interface	1×24-pin ATX power connector
	1×8-pin ATX 12V power connector
	2xUSB connector, can support 2USB2.0 & 2USB3.0
	1xF-AUDIO connector
	1xF-PANEL connector
	1xF-SPEAKER connector
	2x FAN connector
	1x LPC-DEBUG connector
Integrated sound	Realtek ALC 6-channal HD Audio Codec onboard
	provides front audio interface
	provides front stereo mic interface
Storage	4x SATA 3.0(6GB/s) ports
Integrated Lan	Realtek 10/100/1000 Mbps LAN onboard
Expansion Slot	1xPCI Express x16 slot, 1xPCI Express x 1slot
Expansion Slot	1xNVME connector
Dimension	Micro-ATX architecture(17*21cm)
