Bo mạch chủ H81 T-Wolf (DDR3, M-ATX, LGA1150)

Bo mạch chủ H81 T-Wolf (DDR3, M-ATX, LGA1150)

Thương hiệu: T-Wolf

Mã sản phẩm: H81 T-Wolf

800,000₫

Chipset Intel H81 Express, LGA 1150 S/p CPU Haswell Gen 4-5th
RAM 2xDDR3 Dualchannel 1066/1333/1600 MHz s/p Up to 16GB
VGA-HDMI, Lan 1000M, Audio 5.1, 4xUSB2.0x4, 2xUSB3.0
1xM2 NVMe, 1x PCI Express 16X, 1xPCI Express 1X, 3xSata3.0, MicroATX

====================

Bảo hành 36 tháng

Đặc điểm nổi bật

Thông số kĩ thuật

Thương hiệu	T-WOLF
Mã sản phẩm	TW-H81
CPU	Supports CPU Haswell Gen 4-5
CPU	Intel 22nm CPUs (LGA1150)
Chipset	Intel H81 Express Chipset
Memory	2*240-pin DDRⅢ SDRAM slots
	Memory up to 16GB
	Supports dual channal DDR3 1066/1333/1600 MHZ
I/O interface	4xUSB2.0
	2xUSB3.0
	1x VGA port
	1x HDMI port
	1x RJ45 port
	1x 3-in-1 Audio port(line in/line out/MIC in)
Onboard interface	1x 24-pin ATX power connector
	1x 4-pin ATX 12V power connector
	2x USB connector, can support 4*USB 2.0
	1x F-AUDIO connector, 1x F-PANEL connector
	1x F-SPEAKER connector, 1x FAN connector
	1x LPC-DEBUG connector
Integrated sound	Realtek ALC 6-channal HD Audio Codec onboard
	Provides front audio interface
	Provides front stereo mic interface
Storage	1 x SATA 2.0 (3GB/s) ports,2 x SATA 3.0 (6GB/s) ports
Integrated lan	Realtek 100/1000 Mbps LAN onboard
Expansion slot	1x PCI Express x16 slot
	1x PCI Express x1 slot
	1x NVME/NGFF slot
Dimension	Micro-ATX architecture(17*19cm)
